L6360

Name: STMicroelectronics L6360
Brand: STMicroelectronics
SKU: 511-L6360
Price: 9.82 USD
Availability: InStock

Images are for reference only
See Product Specifications

Mouser No:

511-L6360

Mfr. No:

L6360

Mfr.:

STMicroelectronics

Description:

Sensor Interface IO-Link Transceiver 18 to 32.5V 500mA

Complete Your Design

Datasheet:

L6360 Datasheet (PDF)

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

More Information

Learn more about STMicroelectronics L6360

In Stock: 2,187

Stock:: 2,187 Can Dispatch Immediately

An unexpected error occurred. Please try again later.
Factory Lead Time:: 18 Weeks Estimated factory production time for quantities greater than shown.

Enter Quantity:

Minimum: 1 Multiples: 1

Unit Price:

$-.--

Ext. Price:

$-.--

Est. Tariff:

Pricing (USD)

Qty.	Unit Price	Ext. Price
	$9.82	$9.82
	$7.66	$76.60
	$7.12	$178.00
	$6.52	$652.00
	$6.07	$1,517.50
	$5.93	$2,965.00
	$5.86	$5,860.00
2,940	Quote

Alternative Packaging

Mfr. Part No.:

L6360TR

Packaging:

Reel, Cut Tape, MouseReel

Availability:

In Stock

Price:

$4.68

Min:

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	STMicroelectronics
Product Category:	Sensor Interface
RoHS:
Type:	IO-Link Master Transceiver
Interface Type:	IO-Link, Serial
Supply Voltage - Max:	32.5 V
Supply Voltage - Min:	18 V
Operating Supply Current:	4 mA
Minimum Operating Temperature:	- 25 C
Maximum Operating Temperature:	+ 125 C
Mounting Style:	SMD/SMT
Package/Case:	VFQFPN-26
Packaging:	Tray
Brand:	STMicroelectronics
Moisture Sensitive:	Yes
Product:	I/O-Link Transceivers
Product Type:	Sensor Interface
Series:	L6360
Factory Pack Quantity:	2940
Subcategory:	Interface ICs
Unit Weight:	4.400 g

Products found:

To show similar products, select at least one checkbox

Select at least one checkbox above to show similar products in this category.

Attributes selected: 0

Filter Document:

Datasheet

L6360 Datasheet (PDF)

PCN

CNHTS:: 8542399000
CAHTS:: 8542390000
USHTS:: 8542390090
JPHTS:: 854239099
TARIC:: 8542399000
MXHTS:: 8542399901
ECCN:: EAR99

Standard Products

STMicroelectronics Standard Products are a broad range of industry-standard and drop-in replacements for the most popular general-purpose analog ICs, discretes, and serial EEPROMs. The Standard Products are manufactured to the highest quality standards with many AECQ-qualified for automotive applications. A comprehensive set of STMicroelectronics design aids, including SPICE, IBIS models, and simulation tools, is available to make adding to a design-in easy.

L6360 IO-Link Communication Master Transceiver IC

STMicroelectronics L6360 IO-Link Communication Master Transceiver IC is a master port compliant with PHY2 (3 wires) supporting COM1 (4.8kbaud), COM2 (38.4kbaud), and COM3 (230.4kbaud) modes. The C/Q_O output stage is programmable as high-side, low-side, or push-pull; also cutoff current, cutoff current delay time, and restart delay is programmable. Cutoff-current and cutoff-current delay time, combined with thermal shutdown and automatic restart protect the device against overload and short-circuit. The L6360 transfers, through the PHY2(C/Q_Opin), data received from a host microcontroller through the USART (IN C/Q_Opin) or to the USART (OUT C/Q_Ipin), data received from PHY2 (C/Q_Ipin). The L6360 has nine registers to manage the programmable parameters and the status of the IC.
